12", 60w, 96 dB, 8 ohms
- Nominal diameter (") 12
- Power Rating (W) 60
- Nominal impedance (ohms) 8
- Sensitivity (dB) 96
- Chassis type Pressed steel
- Voice coil diameter (") 1 3/4
- Voice coil material Round copper
- Magnet type Ceramic
- Magnet weight 25 oz
- Frequency range (Hz) 70-5000
- Resonance frequency, Fs (Hz) 70
- DC resistance, Re (ohms) 7
-
-
- Mounting Information
- Diameter (mm) 309
- Overall depth (mm) 127
- Magnet structure diameter (mm) 120
- Cut-out diameter (mm) 283
- Mounting slot dimensions (mm) 7.9
- Number of mounting slots 4
- Mounting slot PCD (mm) 297
- Unit weight (kg) 2.7
-
|
