12", 100w, 95 dB, 8 ohms
- Nominal diameter (") 12
- Power Rating (W) 100
- Nominal impedance (ohms) 8
- Sensitivity (dB) 95
- Chassis type Pressed steel
- Voice coil diameter (") 1 1/2
- Cone material Kevlar loaded paper
- Magnet type Ceramic
- Frequency range (Hz) 65-5000
- Resonance frequency, Fs (Hz) 60
- DC resistance, Re (ohms) 5.8
-
-
- Mounting Information
- Diameter (mm) 309
- Overall depth (mm) 124
- Magnet structure diameter (mm) 283
- Mounting slot dimensions (mm) 7.9
- Number of mounting slots 4
- Mounting slot PCD (mm) 297
- Unit weight (kg) 2.35
-
|
